ST-285-2000 Lathe Machine

Product Description

BrandPinachoLength of Carriage550 / 21 3/4 mm / inHeadstock Main Spindle Bore80 / 3 mm / inRapid Traverse X15 mm/minPosition Accuracy0.01 mmSwing Over Bed570 / 22 1/2 mm / inMain Spindle Nose Taper5 MTX Axis Ball Screw and Pitch20/5 mmStations of Standard Automatic Turret8Total Width1605 mmTool Shank25x25 / 1x1 mm / inTail Stock Barrel Travel220 / 8 1/2 mm / inControlControl Fanuc 0i-TF / Fagor 8055i / FL-TC / Siemens 828DBoring Bar40 / 1 1/2 mm / inFixed Steady Capacity180-350 / 7 1/4-13 1/2 mm / inFollow Rest Capacity10-130 / 1/2-5 mm / inCoolant Tank Capacity151 LMain Spindle NoseA2-8 / D1-8Center Distance2000 / 80 mm / inZ Axis Ball Screw and Pitch40/10 mmTotal Height2014 mmBed Width350 / 14 mm / inCoolant Pump Power0.37 kWCoolant Pump Flow25 l/minTotal Weight2970 KgSwing Over Carriage490 / 19 1/4 mm / inLength of Cross Slide600 / 23 1/2 mm / inSpeed Range0-2500 rpmRepeatability0.01 mmCenter Height285 / 11 mm / inSwing Over Cross Slide360 / 14 mm / inRapid Traverse Z12 mm/minWorking Feeds Z X0-7500 mm/minTail Stock Barrel95 / 3 3/4 mm / inTail Stock Morse Taper5 MTMain Motor Power15 kWTotal Length3920 mmVerification StandardDIN 8605Cross Slide Travel300 / 11 3/4 mm / i
