Automatic Conventional Lathe Machine

800000 INR/Unit

Get a Price/Quote

Product Details:

Material MS
Automatic Grade Automatic
Control System Human Machine Interface
Weight (kg) 1680 Kilograms (kg)
Feature High Efficiency
Warranty Yes
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Automatic Conventional Lathe Machine Price And Quantity

Price 800000 INR/Unit
Minimum Order Quantity 1 Unit

Automatic Conventional Lathe Machine Product Specifications

Warranty Yes
Feature High Efficiency
Material MS
Control System Human Machine Interface
Weight (kg) 1680 Kilograms (kg)
Automatic Grade Automatic

Automatic Conventional Lathe Machine Trade Information

Payment Terms Cash in Advance (CID)
Supply Ability 10 Unit Per Month
Delivery Time 30 Days
Main Domestic Market All India

Product Description

Centre Height250 mmLead Screw Rod Pitch6Tool Post Slide Travel130 mmTail Stock Morse Taper4 MTFixed Steady Capacity145Follow Rest Capacity95Centre Distance1500 mmCross Feeds0.020-0.296 mmWidth850 mmBed Width300 mmSpeed Range40-2300 rpmMetric Threads0.5-7.5 mmMaximum Tool Dimensions25 x 25 mmLength2850 mmWhitworth Threads60-4 T.P.I.Pitch Diametral Threads120-8 mmHeight1600 mmSwing Over Gap700 mmSwing Over Bed502 mmPump Motor Power0.1 kWNo of Speed Range3Norton Box No of Pitch44Modular Threads0.25-3.75 mmTail Stock Barrel Travel200 mmLongitudinal Feeds0.044-0.662 mmSwing Over Cross Slide310 mmHeadstock Main Spindle Bore58 mmMain Spindle Morse Taper4 MTMain Motor Power5.5 kWSwing Over Carriage440 mmGap Length In Front of Face Plate160 mmCross Slide Travel250 mmMain Spindle NoseA2 6 / Camlock 6Tail Stock Barrel Diameter68 mmWieght1680 Kg

FAQs of Automatic Conventional Lathe Machine:

Q: What material is used in the construction of the Automatic Conventional Lathe Machine?

A: The Automatic Conventional Lathe Machine is constructed using MS (Mild Steel).

Q: Does the Automatic Conventional Lathe Machine come with a warranty?

A: Yes, the Automatic Conventional Lathe Machine is covered by a warranty.

Q: What is the level of automation in this lathe machine?

A: The Automatic Conventional Lathe Machine has an automatic grade for operational efficiency.

Q: What type of control system does the machine use?

A: The machine is equipped with a Human Machine Interface (HMI) control system.

Q: How much does the Automatic Conventional Lathe Machine weigh?

A: The weight of the Automatic Conventional Lathe Machine is 1680 kilograms (kg).

Q: What is the key feature of this lathe machine?

A: The Automatic Conventional Lathe Machine is designed for high efficiency.
